NODE
The Bluesound NODE opens the door to high-resolution audio streaming and multi-room audio, serving as a contemporary enhancement for existing HiFi systems or favored powered speakers.
SPECIFICATIONS
| Finish | Included Accessories | Storage Environment | Operating Environment |
|---|---|---|---|
| Black/White; Matte Satin Paint | 120V AC Power Cord 230V AC Power Cord Ethernet Cable Stereo RCA to RCA Cable TOSLINK Optical to 3.5mm Mini Adaptor Safety/Warranty Guide Quick Setup Guide | -10°C to 50°C, 20% to 80% relative humidity | 0°C to 40°C |
| Product Weight | Product Dimensions | Shipping Weight | Shipping Dimensions |
| 1.09kg/2.4lbs | 220 x 46 x 146 mm 8.7 x 1.8 x 5.7 in | 2.28kg/5.03lbs | 300 x 300 x 74 mm 11.8 x 11.8 x 2.75 in |
| Status Indicator | Play/Pause Button | Volume Control Buttons |
|---|---|---|
| RGB LED x 2 | Touch LED | Touch Slider LED |
| Previous/Next Track Buttons | Preset Buttons | Proximity Sensor |
| Touch LED | Touch LED x 5 | Yes |
| Operating System | App Controller Operating System | Network File Sharing | Album Art Supported |
|---|---|---|---|
| BluOS | iOS, Android, Windows Vista, 7, 8, 10, macOS 10-11 | SMB up to 200,000 track index | JPG, PNG |
| Internet Radio | Music Services | Voice Control Integrations | 3rd-Party Integrations |
| Click Here | Click Here | Amazon Alexa Skills | AirPlay 2 Spotify Connect Tidal Connect Roon Ready |
| Control Systems | |||
| Control4, Crestron, URC, RTI, ELAN, Lutron |
| Supported Audio File Formats | Supported Hi-Res Audio File Formats | Processor | Native Sampling Rates |
|---|---|---|---|
| MP3, AAC, WMA, WMA-L, OGG, ALAC, OPUS | FLAC, MQA, WAV, AIFF, MPEG-4 SLS | ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core | up to 192 kHz |
| Bit Depths | Performance | DAC | |
| 16-24 | SNR -113dBA THD+N, 0.002% | 32-Bit, 384kHz Differential Output design |
| Network | Audio Input | Audio Output | Bluetooth |
|---|---|---|---|
| Wi-Fi 5 (802.11ac, 2.4/5GHz) Ethernet RJ45, GigE 1000 Mbps | Mini TOSLINK/3.5mm Stereo combo HDMI eARC | Analog Stereo RCA (Fixed or Variable) Coaxial RCA TOSLINK digital optical USB Audio 2.0 | Bluetooth with support for aptX™ HD Two-Way (transmit & receive) |
| Headphone | Subwoofer | USB | Trigger |
| 3.5mm Stereo Out Wireless Bluetooth Out | RCA Out Network Pairing to PULSE SUB+ | Type-A Port for external drive connection (Fat32 or NTFS formatted) | 12V Trigger Out |
| IR Remote | Power | ||
| IR Sensor Built In – front panel with IR Remote Learning IR Input 3.5mm Jack | Universal bi-pin AC cord input (100-240AC) |
DESCRIPTION
The Bluesound NODE introduces a gateway to the realm of hi-res audio streaming and multi-room audio, serving as a contemporary enhancement for existing HiFi systems or favored powered speakers. Uncover an extensive musical universe, accessing countless internet radio stations, numerous streaming services, or your personal digital music library effortlessly through the BluOS Controller app, available on iOS, Android, or Mac and PC computers.
- Seamlessly connect to any existing stereo amplifier, AV receiver, or
- powered audio system for versatile integration
- Powered by an advanced Quad-Core 1.8GHz ARM Cortex A53 processor and a premium 32-bit/384kHz DAC design, ensuring top-notch audio performance.
- Equipped with HDMI eARC connectivity, digital, optical, and analog input/output options, including wired and wireless headphone and subwoofer outputs.
- Facilitates high-resolution audio streaming, providing access to internet radio stations, cloud music services, and your local music library.
- Features dual-band Wi-Fi, Gigabit Ethernet, and 2-way Bluetooth aptX HD, ensuring uninterrupted music playback.
- Intuitive control of a seamless multi-room system through the BluOS Controller app.
- Convenient top panel touch controls with presets for easy access.
- IR input and remote learning capability for compatibility with the optional Bluesound RC1 Remote Controller.
- Integration with the BluVoice skill in the Alexa app enables control through Amazon’s Alexa voice assistant.
- Utilizes AirPlay 2 for synchronized wireless music or podcast playback across your house when connected to wireless stereo components.
AWARDS
“When it comes to multi-room audio, it really doesn't get better than this.”
“When it comes to multi-room audio, it really doesn't get better than this.”
“If you're after one of the best-sounding wireless network speakers around, look no further.”
“If you’re after one of the best-sounding wireless network speakers around, look no further.”
“You won't find a better streamer that's as entertaining and well-featured for this budget price."
“You won’t find a better streamer that’s as entertaining and well-featured for this budget price.”
“This is one of the most musical portable devices I've listened to in a long while and was a genuine pleasure to review.”
“This is one of the most musical portable devices I’ve listened to in a long while and was a genuine pleasure to review.”
“Bluesound’s multiroom wireless system was revolutionary when it first appeared... with a process of refinement and development ever since.”
“Bluesound’s multiroom wireless system was revolutionary when it first appeared… with a process of refinement and development ever since.”
“A superb high-end wireless speaker offering muscular-yet-musical sound and premium design.”
“A superb high-end wireless speaker offering muscular-yet-musical sound and premium design.”
FEATURES
Premium Sound Experience
Experience hi-res audio with the Bluesound Node’s audiophile DAC, supporting 24-bit/192 kHz processing, MQA, and seamless streaming from Tidal, Qobuz, Deezer, Spotify via Wi-Fi, HDMI eARC, Ethernet, AirPlay 2, aptX™ HD Bluetooth, or USB.
Diverse Connectivity Choices
Bluesound Node offers versatile inputs – RCA, TOSLINK optical, aptX™ HD Bluetooth, ensuring optimal performance for streaming services, TV, or personal libraries with hi-res audio.
Immersive Multi-Room Capability
Bluesound Node as the hub of a multi-room setup. BluOS supports 64 players, enabling bit-perfect hi-res audio streaming throughout your home.
User-Friendly Controls
Take control with touch, voice (Siri, Alexa), or Bluesound RC1. BluOS Controller app offers advanced features like tone controls, subwoofer optimization, and settings for external DAC connections.
Smart Home Integration
Effortlessly integrate Bluesound Node into your smart home with drivers for Lutron, Elan, RTI, and Crestron. Experience a seamless blend of high-quality audio and smart home convenience.
Harmonious Multi-Speaker Setup
Connect NODE to Bluesound speakers via BluOS Controller, creating an intuitive, harmonious multi-room music system. Enhance your experience with Bluesound Node – where hi-res music meets cutting-edge technology and customization.
DOWNLOADS
SPECIFICATIONS
| Finish | Included Accessories |
|---|---|
| Black/White; Matte Satin Paint | 120V AC Power Cord 230V AC Power Cord Ethernet Cable Stereo RCA to RCA Cable TOSLINK Optical to 3.5mm Mini Adaptor Safety/Warranty Guide Quick Setup Guide |
| Storage Environment | Operating Environment |
| -10°C to 50°C, 20% to 80% relative humidity | 0°C to 40°C |
| Product Weight | Product Dimensions |
| 1.09kg/2.4lbs | 220 x 46 x 146 mm 8.7 x 1.8 x 5.7 in |
| Shipping Weight | Shipping Dimensions |
| 2.28kg/5.03lbs | 300 x 300 x 74 mm 11.8 x 11.8 x 2.75 in |
| Status Indicator | Play/Pause Button |
|---|---|
| RGB LED x 2 | Touch LED |
| Volume Control Buttons | Previous/Next Track Buttons |
| Touch Slider LED | Touch LED |
| Preset Buttons | Proximity Sensor |
| Touch LED x 5 | Yes |
| Operating System | App Controller Operating System |
|---|---|
| BluOS | iOS, Android, Windows Vista, 7, 8, 10, macOS 10-11 |
| Network File Sharing | Album Art Supported |
| SMB up to 200,000 track index | JPG, PNG |
| Internet Radio | Music Services |
| Click Here | Click Here |
| Voice Control Integrations | 3rd-Party Integrations |
| Amazon Alexa Skills | AirPlay 2 Spotify Connect Tidal Connect Roon Ready |
| Control Systems | |
| Control4, Crestron, URC, RTI, ELAN, Lutron |
| Supported Audio File Formats | Supported Hi-Res Audio File Formats |
|---|---|
| MP3, AAC, WMA, WMA-L, OGG, ALAC, OPUS | FLAC, MQA, WAV, AIFF, MPEG-4 SLS |
| Processor | Native Sampling Rates |
| ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core | up to 192 kHz |
| Bit Depths | Performance |
| 16-24 | SNR -113dBA THD+N, 0.002% |
| DAC | |
| 32-Bit, 384kHz Differential Output design |
| Network | Audio Input |
|---|---|
| Wi-Fi 5 (802.11ac, 2.4/5GHz) Ethernet RJ45, GigE 1000 Mbps | Mini TOSLINK/3.5mm Stereo combo HDMI eARC |
| Audio Output | Bluetooth |
| Analog Stereo RCA (Fixed or Variable) Coaxial RCA TOSLINK digital optical USB Audio 2.0 | Bluetooth with support for aptX™ HD Two-Way (transmit & receive) |
| Headphone | Subwoofer |
| 3.5mm Stereo Out Wireless Bluetooth Out | RCA Out Network Pairing to PULSE SUB+ |
| USB | Trigger |
| Type-A Port for external drive connection (Fat32 or NTFS formatted) | 12V Trigger Out |
| IR Remote | Power |
| IR Sensor Built In – front panel with IR Remote Learning IR Input 3.5mm Jack | Universal bi-pin AC cord input (100-240AC) |
DESCRIPTION
The Bluesound NODE introduces a gateway to the realm of hi-res audio streaming and multi-room audio, serving as a contemporary enhancement for existing HiFi systems or favored powered speakers. Uncover an extensive musical universe, accessing countless internet radio stations, numerous streaming services, or your personal digital music library effortlessly through the BluOS Controller app, available on iOS, Android, or Mac and PC computers.
- Seamlessly connect to any existing stereo amplifier, AV receiver, or
- powered audio system for versatile integration
- Powered by an advanced Quad-Core 1.8GHz ARM Cortex A53 processor and a premium 32-bit/384kHz DAC design, ensuring top-notch audio performance.
- Equipped with HDMI eARC connectivity, digital, optical, and analog input/output options, including wired and wireless headphone and subwoofer outputs.
- Facilitates high-resolution audio streaming, providing access to internet radio stations, cloud music services, and your local music library.
- Features dual-band Wi-Fi, Gigabit Ethernet, and 2-way Bluetooth aptX HD, ensuring uninterrupted music playback.
- Intuitive control of a seamless multi-room system through the BluOS Controller app.
- Convenient top panel touch controls with presets for easy access.
- IR input and remote learning capability for compatibility with the optional Bluesound RC1 Remote Controller.
- Integration with the BluVoice skill in the Alexa app enables control through Amazon’s Alexa voice assistant.
- Utilizes AirPlay 2 for synchronized wireless music or podcast playback across your house when connected to wireless stereo components.
AWARDS
“When it comes to multi-room audio, it really doesn't get better than this.”
“When it comes to multi-room audio, it really doesn't get better than this.”
“If you're after one of the best-sounding wireless network speakers around, look no further.”
“If you’re after one of the best-sounding wireless network speakers around, look no further.”
“You won't find a better streamer that's as entertaining and well-featured for this budget price."
“You won’t find a better streamer that’s as entertaining and well-featured for this budget price.”
“This is one of the most musical portable devices I've listened to in a long while and was a genuine pleasure to review.”
“This is one of the most musical portable devices I’ve listened to in a long while and was a genuine pleasure to review.”
“Bluesound’s multiroom wireless system was revolutionary when it first appeared... with a process of refinement and development ever since.”
“Bluesound’s multiroom wireless system was revolutionary when it first appeared… with a process of refinement and development ever since.”
“A superb high-end wireless speaker offering muscular-yet-musical sound and premium design.”
“A superb high-end wireless speaker offering muscular-yet-musical sound and premium design.”
FEATURES
Premium Sound Experience
Experience hi-res audio with the Bluesound Node’s audiophile DAC, supporting 24-bit/192 kHz processing, MQA, and seamless streaming from Tidal, Qobuz, Deezer, Spotify via Wi-Fi, HDMI eARC, Ethernet, AirPlay 2, aptX™ HD Bluetooth, or USB.
Diverse Connectivity Choices
Bluesound Node offers versatile inputs – RCA, TOSLINK optical, aptX™ HD Bluetooth, ensuring optimal performance for streaming services, TV, or personal libraries with hi-res audio.
Immersive Multi-Room Capability
Bluesound Node as the hub of a multi-room setup. BluOS supports 64 players, enabling bit-perfect hi-res audio streaming throughout your home.
User-Friendly Controls
Take control with touch, voice (Siri, Alexa), or Bluesound RC1. BluOS Controller app offers advanced features like tone controls, subwoofer optimization, and settings for external DAC connections.
Smart Home Integration
Effortlessly integrate Bluesound Node into your smart home with drivers for Lutron, Elan, RTI, and Crestron. Experience a seamless blend of high-quality audio and smart home convenience.
Harmonious Multi-Speaker Setup
Connect NODE to Bluesound speakers via BluOS Controller, creating an intuitive, harmonious multi-room music system. Enhance your experience with Bluesound Node – where hi-res music meets cutting-edge technology and customization.
DOWNLOADS
